Manual roller conveyor with dia.19mm 1.2mm wall pitch 30mm

Product Description:

Products Description

Straight roller conveyor with 19mm diameter,1.2mm wall tubes，pitch 30mm
BR-1912-100W-1000L-30P gravity roller conveyor is used to carry lightweight packages.
This light duty conveyor easily flows product with minimal slope, and is useful when portability is required.

BR - 1912 - W100 - 1000L - 20P
A B C D E

A：Roller Conveyor
B：Roller dia.=19mm, thickness=1.2mm
C：Width of Roller =100mm
D：Conveyor length=1000mm
E：Pitch=20mm

Product Name	BR-1912-W100-1000L-30P
Roller Material	carbon steel
Roller Construction	Round tube, 19mm Diameter, 1.2mm wall tubes
Tube width	100mm~500mm
Bearing	Standard Non-precision. Optional Semi-precision and Precision bearings
Axle retention	6mm galvanized solid shaft.
Frame material	carbon steel
Frame surface treatment	powder painting white
Conveyor length	1000mm~3000mm
Couplings	Butt type for bolting sections together
Supports	Standard is floor supports with ±50mm adjustable legs,optional castors
Pitch	30mm

Products Show

Package and Delivery
